【煙道補償器】鋼廠煙道通風補償器
Flue ventilation compensator for steel works

上海淞江減震器集團有限公司官方網站為您介紹：【煙道補償器】鋼廠煙道通風補償器信息，淞江集團可以為客戶非標定做各種風道煙道補償器產品，可以良好的補償煙道的位移，也可以降低煙道的震動。
Shanghai Songjiang absorber group limited official website for your introduction: [] steel flue ventilation flue compensator compensator information, Songjiang group can provide customers with customized various non-standard air flue compensator can compensate the displacement of products, good flue, can also reduce the vibration of flue.

1 、風道橡膠補償器具有良好的反復位移 ( 變化 ) 還原性，能在較小尺寸范圍內提供較大的多維方向補償，能較好的消除各種管道安裝連接時產生的多向誤差。

2 、風道橡膠補償器具有優越的吸聲隔震功能，能有效的減少和消除鍋爐、風機等系統品聲和震動的傳遞。

3 、橡膠和纖維織無力的傳遞損耗，減少了設計程序，無需增加其它輔助設施。

4 、橡膠和纖維織及隔熱材料具有較高耐熱和耐腐蝕性能，永不生銹，減少維修費用。

5 、風道橡膠補償器具有優異的氣密性和柔順性、能保證輸送介質無泄漏和反復位移后恢復原狀。

1, the air channel rubber compensator has good repeated displacement (change) reducibility, which can provide large multidimensional directional compensation in the smaller size range, and it can eliminate the multi-directional error produced by all kinds of pipeline installation and connection.

2. The air duct rubber compensator has the superior sound absorption and isolation function, and can effectively reduce and eliminate the transmission of sound and vibration of the system products such as boiler and fan.

3. The weak transmission loss of rubber and fiber reduces the design procedure and does not need to add other auxiliary facilities.

4, rubber and fiber fabric and heat insulation materials have high heat resistance and corrosion resistance, never rust, reduce maintenance costs.

5. The rubber compensator of the air duct has excellent air tightness and flexibility, and it can ensure that the conveying medium has no leakage and restores the original shape after repeated displacement.

風道橡膠補償器橡膠材質可以選擇天然橡膠、三元乙丙橡膠、和硅橡膠三種，這三種橡膠耐溫如下：天然橡膠80度以下，三元乙丙橡膠120度以下，硅橡膠200度以下。

The rubber material of the rubber compensator of the air channel can choose three kinds of natural rubber, three yuan ethylene propylene rubber and three silicone rubber. The three kinds of rubber temperature resistance is as follows: natural rubber is below 80 degrees, three yuan, ethylene propylene rubber is below 120 degrees, and silicone rubber is below.
